GE FANUC IC693MDL646 Discrete Input Module 16 Channels 0-30 VDC

GE FANUC IC693MDL646 TYPICAL SCAN RATE SERIES 90-30 PROCESSOR MODULE



Technical Specifications for IC693MDL646

Brand	GE Fanuc
Series	Series 90-30
Manufacturer	GE Fanuc
Product Description	Discrete input module
Part Number	IC693MDL646
No of Channels	Sixteen (16)
Rated Voltage	24 Volts DC
Input Voltage Range	0 to +30 Volts DC
Wiring configuration	Positive / Negative logic
Inputs per Module	16 (one group with a single common)
Input signal range	0-30 VDC
Isolation	1500 Volts between field side and logic side
Nominal Input voltage	24 VDC
Input Current	7 mA per channel



Current draw	80 mA @ 5VDC; 125 mA @ 24 VDC
On-state Voltage	11.5 to 30 Volts DC
On State Voltage	11.5 - 30.0 VDC
Off-state Voltage	0 to +5 Volts DC
Off state voltage	0-5 VDC
On-state Current	3.2 mA minimum
On state current	3.2 mA
Off-state Current	1.1 mA maximum
Off state current	1.1 mA
On response time, typical	1 ms
Off response time, maximum	1 ms
Product Lifecycle Status	Discontinued/Obsolete







About IC693MDL646



The IC693MDL646 is a component module of the Series 90-30 Programmable Logic Controller (PLC) platform that is manufactured by formerly

by GE Fanuc, now by Emerson Automation. This module is designed to accept 24 VDC input signals and supports Positive and Negative logic

wiring configuration.

The IC693MDL646 has a single group of Sixteen (16) input channels. It comes with a common power input terminal with 1 ms On and Off

typical response time. This module is designed to accommodate a wide variety of Binary or On/Off field devices such as push button devices,

switches, proximity switches and auxiliary contacts. This module accepts an input voltage range of 0-30 VDC with nominal value of 24 VDC

and input current of 7 mA at rated voltage.

Input characteristics of this module includes an On state voltage of 11.5 VDC - 30 VDC; Off state voltage of 0 VDC - 5 VDC; On state current

of 3.2 mA (minimum); Off state current of 1.1 mA (maximum) and Power consumption of 80 mA @ 5VDC for 5VDC bus voltage and 125 mA

@ 24VDC bus voltage or user provided power supply.

The IC693MDL646 comes with Twenty (20) connection terminals. These terminals are covered by a swing door with the swing door also

providing the wiring insert as reference on how to establish connection to devices and power sources. This module follows a color-code

indicating that the IC693MDL646 is a low-voltage module. Individual channel status LEDs are also installed as well as Module OK LED.

The IC693MDL646 module is a GE Fanuc 24 Volts DC module classified under Series 90-30 of the GE programmable logic controllers.
