GE FANUC IC693MDL231 Typical Scan Rate Of 0.22 Ms Per 1K Of Logic

GE FANUC IC693MDL231 Typical Scan Rate Of 0.22 Ms Per 1K Of Logic

Technical Specifications for IC693MDL231

Brand GE Fanuc
Series Series 90-30
Part Number IC693MDL231
Brand GE Intelligent Platforms/GE Fanuc
Product Type Isolated Input Module
Voltage 240 V AC
Inputs 8

Frequency 50/60 Hz
Input Current at a Rated Voltage 15 mA
Isolation between field side and logic side 1500 V RMS
AC Power Yes
DC Power No
LED Indicators 8



About IC693MDL231

The IC693MDL231 isolated input module is a product of the GE Intelligent Platforms/GE Fanuc. It belongs to the Series 90-30

product line and it operates on a voltage of 240 Volts AC. This module is well-matched with the GE Series 90-30 PLCs. This

input module comprises 8 isolated input points, with each point having a single power input terminal. It has input properties

that make it best for use with different input devices which can be operated with the IC693MDL231 module due to its input

features. These devices include electronic proximity switches, limit switches, and pushbuttons which can be operated when

the users supply an external source of power. This input module does not use DC power because it is an AC module.





The GE Fanuc IC693MDL231 input module, like many other Series 90-30 modules, features an LED block located on the top of

this device. This module comes with 8 LEDs in a single row that show the "ON" and "OFF" status for input points 1 to 8. It also

has a door panel on the front that allows for an insert between the interior and exterior surfaces. The outer surface of the insert

records the information on circuit identification whenever the door closes. Additionally, there will be circuit wiring information

on the interior surface of the insert. The insert comes with a red edge, which indicates that the IC693MDL231 module is a

high-voltage device. The operators of this module have the ability to install an input module in any of the 5-slot or 10-slot

baseplates of the Series 90-30 PLC by using the input and output slots.
