GE FANUC IC693CMM301 SERIES 90-30 PROGRAMMABLE LOGIC CONTROLLER (PLC)

GE FANUC IC693CMM302 SERIES 90-30 PROGRAMMABLE LOGIC CONTROLLER

Technical Specifications for IC693CMM302

Manufacturer GE Fanuc
Series Series 90-30
Manufacturer GE Fanuc / Emerson Automation
Series Series 90-30
Part Number IC693CMM302
Product Description Genius communication module
Product Type Enhanced Genius Communications Module
Number of Bus Devices Supported 31
Slot width Single slot
Compatible Host Device GE Series 90-30 PLC
Slot assignment Any slot except CPU slot
Compatible Baseplates CPU, Expansion, and Remote Baseplates
Mounting location Series 90-30 baseplate

LEDs 2 (OK LED and COM LED)
Number of supported devices 31
Data Monitoring By an Industrial or Personal Computer
Global Data length (Transmit) 128 Bytes
Compatible with GCMs Not Compatible
Global Data Length (Received) 128 bytes
Product Lifecycle Status* Discontinued/Obsolete
Supported Registers %G, %I, %Q, %AI, %AQ, and %R
Status LED indicators Module OK; COMM
No. of modules per PLC Up to 2 devices
Backplane current draw < 300 mA at 5VDC



About IC693CMM302

The IC693CMM302 is a Genius Communication module belonging to the Series 90-30 Programmable Logic Controller (PLC)

series of Emerson Automation, formerly by GE Fanuc automation. This module is a single-slot width module, providing Genius

protocol connectivity, enabling communicating with up to 31 devices and a maximum of 62 devices per controller as the Series

90-30 systems permit configuration of up to Two (2) IC693CMM302 per controller. The IC693CMM302 allows 128 bytes of

transmitted and 128 bytes of received Global data per IC693CMM302 and supports PLC registers such as Global register (%G),

Discrete Input (%I), Discrete output (%Q), Analog input (%AI), Analog output (%AQ), and Register memory (%R). It supports

software-based diagnostics such as status bits, fault reporting to series 90-70 PLC. Environmental ratings of this module include

0 oC to +60 oC (+32 oF to +140 oF) operating temperature; Storage temperature of –25 oC to +70 oC (– 13 oF to +158 oF);

Humidity of 5% to 95% (non–condensing) while the mechanical ratings include 0.2-inch displacement 5Hz to 10Hz and 1 G

10Hz to 200Hz operating vibration and operating shock of 5 G 10Ms duration. Aside from Global data exchange, the

IC693CMM302 allows data monitoring through a personal or industrial computer, monitoring data with the use of I/O blocks,

device communication over the Genius bus, and I/O emulation. The IC693CMM302 has a backplane power consumption of

<300 mA at 5VDC. Aside from Series 90-30 PLC, it can be used with Series 90-70, Series Six PLCs as well as the Genius

Hand-Held Monitor (HHM) for local configuration.

The Series 90-30 IC693CMM302 communication module was designed and manufactured by GE Fanuc to be a GCM+ device,

also known as an enhanced Genius communications module. The IC693CMM302 enhanced Genius communications module can

communicate with global data between up to 32 devices. These devices are a GE Series 90-30 PLC and 31 other devices that

are connected to a genius bus. It is recommended to install the IC693CMM302 enhanced Genius communications module on

the CPU baseplate of the host PLC system for the most efficient operation, but it can also be installed on the remote baseplates

or the expansion baseplates in the same system. However, enhanced Genius communications modules cannot be installed in

PLCs that have regular Genius communications modules or GCMs in them.

Multiple enhanced Genius communications modules like the IC693CMM302 module can be installed in a single PLC system, and

each enhanced Genius communication module has its own genius bus, which means that each of these modules can connect to

and communicate with up to 31 additional devices at a time. For example, a Series 90-30 GE PLC that has 2 enhanced Genius

communications modules in it can communicate with as many as 62 additional devices at a time. The IC693CMM302 enhanced

Genius communications module is primarily used to exchange global data, but it can also handle data monitoring with an

industrial or personal computer, peer-to-peer communication and master-slave communication between the bus devices, and

data monitoring from the genius I/O blocks (note that the communications module cannot control these I/O blocks.
