1769‐IT6 Digital I O Module AB Input Module CompactLogix

Product Details:

Place of Origin:	Japan
Brand Name:	AB
Certification:	CE
Model Number:	1769‐IT6

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiated
Packaging Details:	New Original
Delivery Time:	3-5days
Payment Terms:	L/C, T/T
Supply Ability:	1000

Contact Now

Detailed Product Description

Brand:	AB	Product Type:	Digital I O Module
Part Number:	1769‐IT6	Place Of Origin:	Japan
Signal Range::	4...20mA, 0...20mA	Temperature Rating::	-20...55 Â°C (-4...131 Â°F)

1769‐IT6 Digital I O Module AB Input Module CompactLogix

Product Description of 1734-IE8C AB

Brand:AB
Depth:87mm, 3.43"
Display:Status LEDs
Enclosure:None (open-style)
GX rating:None
Height:118mm, 4.65"
Mounting:DIN Rail / Panel mount

Special Features:Thermocouples Supported: B, E, J, K, R, S, T, N, C
Sub Brand:CompactLogix
Type:Analog Input Module
Width:35mm, 1.38"

Technical Specifications for 1769-IT6

Product Family:	Compact I/O Modules
Power Supply Distance Rating:	8 modules
CJC accuracy:	±1.0 °C (±1.8 °F)
CJC sensor accuracy:	±0.3 °C (±0.54 °F)
Calibration:	Performed during power-up; programmable
Nonlinearity:	±0.03%
Heat dissipation, max:	1.5W
Current draw @ 24V:	40 mA
Current draw @ 5.1V:	100 mA
millivolt signal:	+/- 50mV and +/-10mV
Sensors supported:	J, K, T, E, R, N, S, B, N, C, CJC,
Compatible Adapters:	1769-ADN (DeviceNet); 1769-AENTR (Ethernet)
No. of Inputs:	6
Part Number:	1769- IT6
Product Type:	Thermocouple / milivolt Input Module
Manufacturer	Rockwell Automation / AB

About 1769-IT6

The AB 1769-IT6 Thermocouple/mV Input Module is a compact device that measures thermocouple and millivolt signals. These measurements are digitally converted and stored as analog data in any combination of up to six thermocouple or millivolt analog sensors. Over-range, under-range, open-circuit detection, and indication are provided.

The 1769-IT6 Compact Input Module has 6 input channels plus 2 CJC sensors. It has a Delta Sigma converter type and its response speed per channel is input filter and configuration dependent. It communicates with the controller via the bus interface where it also receives power from the 5-24V DC system power supply. The 1769-IT6 module draws a maximum current of 100 mA at 5 Volts DC, and 40 mA at 24 Volts DC. Upon powerup and when a channel is enabled, this input module performs auto-calibration. Auto-calibration can also be programmed to run every five minutes.
The 1769-IT6 is UL 508 listed, C-UL certified (under CSA C22.2 No. 142), and CE compliant for applicable directives. It can be attached to an adjacent I/O module or to the controller before or after (single module replacement) mounting. To reduce electrical noise, install this measurement device at least two slots away from an AC power supply. When mounting, maintain a minimum spacing clearance of two inches on all sides for adequate ventilation.

This module is ideally useful in temperature applications as Thermocouple instruments are used specifically for temperature measurement. Additionally, millivolt signals are typically used for interfacing transducers.

This module is specifically compatible for measurement of temperature such as -210...+1200 °C for Temperature Type J, -270...+1370 °C for Type K, -270...+400 °C for Type T, -270...+1000 °C for type E, 0...+1768 °C for Type R, 0...+1768 °C for Type S, +300...+1820 °C for Type B, 210...+1300 °C for Type N and 0...+2315 °C for Type C Thermocouples. Each of the analog input can be configured for Engineering units, Scaled for PID, and Raw / Proportional Data.

This module is designed with the capability of sensing open circuit, short-circuit, over-range, and under-range detection for each of the Six (6) channels. Selectable input filters are also available to stabilize measurement. Selectable input filters include 10 Hz, 50 Hz, 60 Hz, 250 Hz, 500 Hz and 1 kHz.

The module does not require an external power supply. It occupies a single slot in the chassis and receives 5VDC and 24VDC power from the communication bus.
