| Place of Origin: | USA |
| Brand Name: | GE |
| Model Number: | IC200CHS003 |
| Price: | negotiation |
|---|---|
| Packaging Details: | New in original boxRockwell Automation |
| Delivery Time: | 5-8 work daysRockwell Automation |
| Payment Terms: | T/T |
| Supply Ability: | 1 |
| Condition: | New | Nominal Output Voltage: | 120 / 240 VAC |
|---|---|---|---|
| Product Type: | Input Module | Warranty: | 1 Year |
| Memory Requirement: | 16 Bytes | Rated Voltage: | 11 Watts |
| Output Voltage Range: | 5 Volts DC And 3.3 Volts DC | Communication Rate: | 16 Outputs |
GE IC200CHS003 I/O CARRIER VERSAMAX LOCAL CONNECTOR STYLE INTEGRATED TYPE VERTICAL ORIENTATION
Product information GE IC200MDL640 :
IC200CH003 is a connector-style carrier I/O manufactured by GE Fanuc automation. The IC200CH003 I/O carrier weighs 0.113 kilograms and comes with a 36-pin connector used for attaching an Input / Output cable. The carrier gives a provision for backplane communications, mounting as well as field wiring for one Input / Output module. You can locate a module latch hole for fastening the module onto the carrier. The carrier also provides fast attachment for wiring up to 32 input / output points and 4 common power connections.
During rail mounting, the IC200CH003 I/O carrier easily snaps onto DIN rail with the following dimensions: 7.5 mm x 35 mm. To provide EMC protection, the DIN must be electrically grounded. They must also have a conductive and corrosion-resistant finish. Field wiring connections are done directly onto the connector style itself with the help of contacts which are crimped to the wire ends. I/O devices can be wired directly to Interposing I/O Terminals. For installation of a pre-wired connecting cable, the cable connector is placed over the connector located on the carrier and later pressed downward until the latch engages with the connector.
To remove the cable, the connector must be held and pressed up on the latch to release the connector. Sometimes, the operating equipment might get hot due to high ambient temperature. When this happens, exercise caution when handling the connector. Be advised not to touch it directly. Also steer clear of exposed connector pins. A connector kit for fabricating custom cables is available and comes with a connector and a cover, 6 large contacts, 2 screws, and 36 small contacts.
Features:
Powerful and Reliable VersaMax controllers provide powerful, reliable operation. Modular, high-density VersaMax IO is versatile, compact, and affordable.
Its scalable architecture and ease of use save time and money for both machine builders and end users. Media redundancy and hot swap capability increase uptime. A broad range
Designed to minimize costs, these versatile controllers are easy to use and support and offer a wide range of I/O expansion modules and communications options.
More information:
| Mounting | DIN rail |
| Current per Point | 2 Amps |
| Current per Power and Ground | 8 Amps |
| Max Voltage Transients | 300 Volts AC |
| I/O Module Mounting | Vertical |
| IC694MDL230 | 120 VAC Isolated Input (8 Points) |
| IC694MDL231 | 240 VAC Isolated Input (8 Points) |
| IC694MDL240 | 120 VAC Input (16 Points) |
| IC694MDL241 | 24 VAC/VDC Input (16 Points) |
| IC694MDL250 | 120 VAC Isolated Input (16 Points) |
| IC694MDL260 | 120 VAC Input (32 Points)** |
| IC694MDL632 | 125 VDC Input (8 Points) |
| IC694MDL634 | 24 VDC Input, Neg/Pos Logic (8 Points) |
| IC694MDL645 | 24 VDC Input, Neg/Pos Logic (16 Points) |
| IC694MDL646 | 24 VDC Input, Neg/Pos Logic, 1 msec Filter (16 Points) |
| IC694MDL654 | 5/12 VDC (TTL) Input, Neg/Pos Logic, (32 Points) |
| IC694MDL655 | 24 VDC Input, Neg/Pos Logic, 1 ms, (32 Points) |
| IC694MDL660 | 24 VDC Input (32 Points)** |
| IC694ACC300 | Input Simulator Module (8 Points) |
