| Place of Origin: | USA |
| Brand Name: | GE |
| Model Number: | IC200PWR001 |
| Price: | negotiation |
|---|---|
| Packaging Details: | New in original boxRockwell Automation |
| Delivery Time: | 5-8 work daysRockwell Automation |
| Payment Terms: | T/T |
| Supply Ability: | 1 |
| Condition: | New | Nominal Output Voltage: | 120 / 240 VAC |
|---|---|---|---|
| Product Type: | Output Module | Warranty: | 1 Year |
| Memory Requirement: | 4 Bytes | Rated Voltage: | 11 Watts |
| Output Voltage Range: | 5 Volts DC And 3.3 Volts DC | Communication Rate: | 311, 313, And 323 |
GE IC200PWR001 18 to 30VDC 24VDC nominal 11W 10ms high-density VersaMax IO is versatile
Product information GE IC200PWR001 :
24VDC Power Supply IC200PWR001 provides backplane power for CPU, NIU, and I/O modules. It supplies up to 1.5 Amps output current via 3.3 volt and 5 volt outputs, with up to 0.25 Amp on the 3.3 Volt output. This is ample power for most installations. Module backplane current consumption is summarized in appendix C
More information:
| Holdup Time | 10 Milliseconds |
| Inrush Current | 20 A at 24 VDC and 25 A at 30 VDC |
| Protection | Short circuit, overload, reverse polarity |
| Total Output | 1.5 A maximum |
| 3.3V Output Current | 0.25 A maximum |
| 5V Output Current | 1.5 A minus the 3.3 V current used, maximum |
| Dimensions (W x H x D) | 133.4 mm (5.25 in) x 39 mm (1.54 in), not including the height of the carrier or the DIN-rail |
IC200PWR001 's details:
| IC694MDL230 | 120 VAC Isolated Input (8 Points) |
| IC694MDL231 | 240 VAC Isolated Input (8 Points) |
| IC694MDL240 | 120 VAC Input (16 Points) |
| IC694MDL241 | 24 VAC/VDC Input (16 Points) |
| IC694MDL250 | 120 VAC Isolated Input (16 Points) |
| IC694MDL260 | 120 VAC Input (32 Points)** |
| IC694MDL632 | 125 VDC Input (8 Points) |
| IC694MDL634 | 24 VDC Input, Neg/Pos Logic (8 Points) |
| IC694MDL645 | 24 VDC Input, Neg/Pos Logic (16 Points) |
| IC694MDL646 | 24 VDC Input, Neg/Pos Logic, 1 msec Filter (16 Points) |
| IC694MDL654 | 5/12 VDC (TTL) Input, Neg/Pos Logic, (32 Points) |
| IC694MDL655 | 24 VDC Input, Neg/Pos Logic, 1 ms, (32 Points) |
| IC694MDL660 | 24 VDC Input (32 Points)** |
| IC694ACC300 | Input Simulator Module (8 Points) |
