| Brand: | Fanuc | PN: | A02B-0236-C231 |
|---|---|---|---|
| Category: | Controller | Deliver: | 3-5days |
| MOQ: | 1 PCS | Warranty: | 1 Year |
| Highlight: | 240m/min Operator Panel,Fanuc Cnc Operator Panel,A02b-0236-C231 |
||
Axis Control
Digital Servo Function 1 Controlled Path 2 (up to maximum of 4) Simultaneously Controllable Axes (J801) (J803) Serial Encoder Interface Axis Names Selected from X,Y,Z,A,B,C Least Input Increment of 0.001mm, 0.0001", 0.001deg Inch/Metric Conversion (J876) Interlock per Axis Machine Lock Emergency Stop Overtravel Signal Stored Stroke Check 1 Mirror Image Follow-up Function Servo Off Mechanical Handle Feed Backlash Compensation Stored Pitch Error Compensation (J841)
Operation
Memory Operation DNC Operation MDI Operation Program Number Search Sequence Number Search Buffer Register Dry Run Mode Single Block Mode Manual Feed Mode (Jog) Manual Reference Point Return Manual Handle Feed (J835) (requires MPG) Incremental Feed
Interpolation
Positioning (G00) Linear Interpolation Circular Interpolation Dwell (G04) Threading Skip Function (G31) Torque-limit Skip Automatic Reference Point Return (G28, G29) Reference Point Return Check (G27) 2nd Reference Point Return (G30)
| A06B-0076-B403 A06B-2076-B403 | A06B-2257-B110 A06B-0257-B110 |
| A06B-1411-B153 | A06B-2257-B100 A06B-0257-B100 |
| A06B-1411-B553#0R02 | A06B-1445-B103 |
| A06B-2239-B100/0239-B100 | A06B-0085-B107 A06B-2085-B10 A06B-0085-B103 |
| A06B-0223-B100/2223-B100 | A06B-0078-B003 A06B-2078-B003 |
| A860-2235-B202#0100 | A06B-1420-B901/900#F321 |
| A06B-0236-B100/2236-B100 | A06B-0292-B110#0035 ais200/3000 |
| A06B-0235-B202 A06B-2235-B202 | A06B-0064-B303 A06B-2064-B303 |
| A06B-1426-B103 | A06B-0076-B403 A06B-2076-B403 |
| A06B-0243-B200 | A06B-1411-B153 |
| A06B-0085-B503 A06B-2085-B503 | A06B-1411-B553#0R02 |
| A06B-1409-B153 aiI15/7000 | A06B-2239-B100/0239-B100 |
| A06B-0063-B403 A06B-2063-B403 | A06B-0223-B100/2223-B100 |
| A06B-0275-B110 A06B-2275-B110 | A860-2235-B202#0100 |
| A06B-0269-B100 | A06B-0236-B100/2236-B100 |
| A06B-0235-B805 A06B-0235-B600 | A06B-0235-B202 A06B-2235-B202 |
| A06B-0226-B400 C8/2000I | A06B-0243-B401 |
| A06B-0243-B101 | A06B-2215-B000 aiS 4/5000-B |
Feed Function
Rapid Traverse Feedrate 240m/min (100m/min @0.0001mm increment) Rapid Traverse Feedrate Override (preset value, 25%, 50%, 100% settings) Feed per Minute Feed per Revolution Tangential Speed Control Cutting Feedrate Clamp Automatic Acceleration/Deceleration (Rapid Traverse: Linear; Cutting Feed: Linear or Exponential) Rapid Traverse Bell-Shaped Acceleration/Deceleration Feedrate Override 0-254% Jog Override 0-655.34 % Override Cancel Manual Synchronous Feed
Programming
EIA/ISO Automatic Identification Label Skip Parity Check Control In/Out Optional Block Skip Maximum Programmable Value - 8 digits Program Number - O with 4 digits Sequence Number - N with 5 digits Absolute or Incremental Command Programmable Data Input (G10) Decimal Point Input Setting in Diameter or Radius Plane Selection (G17, G18, G19) Rotary Axis Setting Rotary Axis Rollover Coordinate System Setting (G50) Automatic Coordinate System Setting Coordinate System Shift Direct Coordinate System Shift Setting Manual Absolute On/Off G Code System A Subprogram Calling Canned Cycles Multiple Repetitive Canned Cycles (G70-G76) (J877) Specifying the Radius of an Arc
Auxiliary and Spindle Functions
Miscellaneous Function - M with 8 digits Miscellaneous Function Lock High Speed M/S/T Interface Multiple Commands of Miscellaneous Functions (up to 3) Spindle Function - S with 5 digits Serial Spindle Interface (J850) Constant Surface Speed Control (J855) Spindle Override 0-254%
